Champak Steel & Engg. Co is one of the leading manufacturers, suppliers and stockiest of a wide range of Rockstar 500 Plates that meet industrial desires. The plates are manufactured using approved and well tested raw material sourced from a trusted vendor. We are offering Rockstar 500 Plates in a variety of standards, sizes, wall thickness, and dimensions that fulfil diverse industrial demands. The plates are also supplied in custom made specifications based on the exact demands of our clients. Rockstar 500 is wear-resistant steel containing manganese, carbon, chromium, phosphorous, silicon, sulfur, molybdenum, boron and nickel. This excellent chemical composition offers mechanical and physical properties in abrasive environments. We precisely design Rockstar 500 Plates complying all the national and international standards. We use different welding techniques like manual electric welding, inert gas and submerged arc welding to get desired specifications and quality. These plates have many good features such as superior surface finish, high strength, anti-corrosiveness, pitting resistance, longevity and higher durability. Rockstar 500 Plates are resistant to crevice corrosion and stress corrosion cracking.
Champak Steel & Engg. Co holds many years of experience in developing quenched and tempered Rockstar 500 Plates. These plates have an outstanding combination of formability and weldability to meet the exact needs of industries. Our skilled and dedicated workforce is producing these plates using modern manufacturing methods. These plates are widely suitable for mining and construction purposes. We are offering cost-effective and efficient Rockstar 500 Plates that makes us stand apart from other suppliers. Our experts add the factor of innovation while manufacturing plates to fulfil all the requirements. We are providing Rockstar 500 Plates for a broad range of industrial applications like conveyor buckets, cutting edges, dump trucks, hoppers, ore scrappers, chute liners, slurry pipe systems etc. The remarkable hardness and strength make the plates sustainable in harsh environments and heavy loads. Rockstar 500 Plates are perfectly reliable for industries that demand higher wear and tear resistance. The entire production is done under strict supervision to offer the best quality.
At Champak Steel & Engg. Co, we have a highly developed and equipped manufacturing unit with modern tools. In order to maintain the quality and performance of Rockstar 500 Plates, we conduct several quality checks during the manufacturing process. We serve precise and high-performance plates by performing rigorous tests under the supervision of experts. This process is carried out mandatorily to ensure no poor quality plates are supplied. We are consistently upgrading our manufacturing methods and equipment to improvise the quality Rockstar 500 Plates by maintaining the affordable cost. We offer all important documents and test certificates to our buyers that contain all details and make sure the high quality of products.
Champak Steel & Engg. Co understands the importance of appropriate packaging of Rockstar 500 Plates. The plates are packed in adequate material for assuring the damage-free and safer delivery. The doorstep and timely delivery of Rockstar plates is guaranteed. We deliver the products through a convenient shipping mode to the desired locations of our esteem customer.
Rockstar 500 Plates Specifications
Thickness : 6mm to 100mm
Width : 1,500mm to 2,500mm
Length : 6,000mm to 12,000mm
Production : Hot-Rolled (HR) / Cold-Rolled (CR)
Heat Treatment : N, Q+T
Surface Paint : EP, PE, HDP, SMP, PVDF
Chemical Composition of Rockstar 500 Plates
Plate Thickness | C | Mn | P | S | Si | Cr | Ni | Mo | B | CE | PCM |
---|---|---|---|---|---|---|---|---|---|---|---|
mm | Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max | Max |
6.0 – 20.0 | 0.60 | 0.41 | |||||||||
21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.0040 | 0.65 | 0.43 |
41.0 – 50.0 | 0.74 | 0.48 |
Mechanical Properties Of Rockstar 500 Plates & Sheets
Hardness | 450-540 BHN (On a milled surface 0.5-2 mm below the plate surface) | |||
---|---|---|---|---|
Yield Strength (MPa) | Tensile Strength (MPa) | % Elongation | Impact at 20°C | |
(L0=50 mm) | (In Joules) | |||
Typical values for 15 mm | 1250 | 1500 | 8 | 27 |
Rockstar 500 Plates Application Industries
Our Rockstar 500 Plates are used in a wide range of applications and various industries. Below are a few of them:
Conveyor Buckets
Drag line Bucket Wear Liners
Dump Truck Liners
Cutting Edges
Crusher Liner Plates
Screen Plates - Chute Liners
Ripper Tyne
Loading Buckets
Bulldozers
Hoppers
Champak Steel and Engg. Co. is one of the leading manufacturer and supplier of Rockstar 500, Rockstar 500 Plates, Abrasion/Wear Resistant Steel Plates Rockstar 500, Rockstar 500 Steel Plate at the best price in India.
